Sensor initialization

Each sensor must be initialized with the IP address corresponding to its corresponding server port

Server port	Server Port	Sensor IP address	Sensor Mask
1	192.168.11.1	192.168.11.2	255.255.255.252
2	192.168.11.5	192.168.11.6	255.255.255.252
3	192.168.11.9	192.168.11.10	255.255.255.252
4	192.168.11.13	192.168.11.14	255.255.255.252
5	192.168.11.17	192.168.11.18	255.255.255.252
6	192.168.11.21	192.168.11.22	255.255.255.252
7	192.168.11.25	192.168.11.26	255.255.255.252
8	192.168.11.29	192.168.11.30	255.255.255.252

For example, if you have a pro4 server with 4 sensors, you should configure the sensors this way :

Sensor initialized with IP 192.168.11.2 can be wired only to port 1 → label it sensor #1 Sensor initialized with IP 192.168.11.6 can be wired only to port 2 → to be labelled sensor #2 Sensor initialized with IP 192.168.11.10 can be wired only to port 3 → to be labelled sensor #3 Sensor initialized with IP 192.168.11.14 can be wired only to port 4 → to be labelled sensor #4

Advanced

IP address initialization tutorial for each sensor is there :

Sensors

⚠️

Once initialized, each sensor can only be plugged to its corresponding port, so please always label your sensor with the port number ! (and even better, also the IP address).

💡
